4" Mopar Lift Kit Features
Ideally rated coil springs, combined with your choice of specially tuned shock absorbers, provide
unmatched ride quality and handling, both on-road and on the trails.
Choose between Mopar's Performance shock or the premium Bilstein Shock.
Learn more about Mopar Shocks
Adjustable alignment cams (at lower link arms-to-axle attachment points) correct caster angle.
Front body / frame alignment corrected by an adjustable track bar; the rear is handled via a track bar
relocation bracket with integrated brace.
Correct length stabilizer bar links with Heim ends.
Brake hose and parking brake cable relocation brackets.
Replacement high-clearance, high-capacity steering stabilizer kit.
Works with all vehicle systems including the Electronic Stability Control.
Check out the Mopar Lifetime Limited Warranty
4" Mopar Lift Kit Parts
| Part # | Description | Application |
|---|---|---|
| P5155403AB | 4" Short Arm Lift Kit w/ Performance Shocks | 2007-2011 JK 4 door 4WD* |
| P5155404AB | 4" Short Arm Lift Kit w/ Bilstein Shocks | 2007-2011 JK 4 door 4WD* |
| P5155512 | Front Stabilizer Bar Link Kit | 2007-2011 JK 4WD Rubicon w/2" or 4" Lift Kit |
| * Rubicon model requires Front Stabilizer Bar Link Kit number P5155512. | ||
Wheel & Tire Recommendations
Tire Diameter: 33" to 35"
Maximum Tire Width: 12.5"
Tires wider than 10.5" may require wheels with dimensions as follows:
Wheel Diameter: No less than 17"
Wheel Width: 8" to 9"
Wheel Backspacing: 3.25" to 4.75"
(as backspacing dimension decreases, track width & stability increase)
Maximum Tire Width: 12.5"
Tires wider than 10.5" may require wheels with dimensions as follows:
Wheel Diameter: No less than 17"
Wheel Width: 8" to 9"
Wheel Backspacing: 3.25" to 4.75"
(as backspacing dimension decreases, track width & stability increase)
Installation Time
6.5 hours for a professional technician familiar with installation. Not including front-end alignment.
